Product Detail

The 200W Spektrum™ S1200 Smart G2 AC Charger provides easy charging for all modelers, especially using Smart batteries — with Auto Charge simplicity, one-connection balancing, IC3® or IC5® output ports for adapter-free convenience, and more.

Features

• Delivers 200W power for charging

• Charges AND balances Smart G2 batteries with one simple IC3® or IC5® connection — no separate balance lead needed

• Auto Charge recognizes Smart battery charging parameters and begins safe, accurate charging automatically when connected

• Charges virtually any RC battery (use Smart batteries to benefit from all charger features)

• Smart software tracks and stores numerous Smart battery data

• Includes IC3® and IC5® charging output ports — no separate adapters required to charge different Spektrum™ Smart batteries

• An on-screen clock counts down remaining charge time until your Smart battery is fully charged and ready to use

• Updated user interface features fresh, intuitive menus, icons and navigation tools, plus non-slip, easy-to-use buttons

• USB input and output ports are included for updating firmware and charging secondary devices

• ON/OFF switch eliminates the need to plug in and unplug the power cord for on/off control

• Detachable power cord makes transporting more convenient

• Includes an efficient, low-noise cooling fan

• Compact size and sleek, sturdy case fits well on a workbench and in pit or field bags

• Handy rubber grips on case make it easier to plug in and remove batteries
  IC3® and IC5® connectors are backwards compatible with EC3™ and EC5™ connectors

Specifications

• Product Length: 5.7' (145 mm)

• Product Width: 5.7' (145 mm)

• Product Height: 4.1' (104 mm)

• Thermal Protection: Yes

• Discharge: 0.1 - 1.5A (10W Max)

• Maximum Charge Rate: 15 or More Amps

• Reverse Polarity Protection: Yes

• Integrated Balancing: Yes - Internal Balancer & Internal Adapter

• Maximum Continuous Discharge Current: 10W

• Software Updates: Yes

• Technology: Smart

• Display: 2.4' 320 x 240 IPS LCD

• Hard Case: Yes

• Input Voltage: 100-240V AC

• Part Type: Electronics

• Power (watts): 200 - 399W

• Amp Meter: Yes

• Application: RC model battery charger

• Output Connector: IC3, IC5

• Peak Detection: Yes

• Product Weight: 2.2lbs (1015g)

• Short Circuit Protection: Yes

• Battery Type: Smart, Non Smart

• PC Connectivity: Yes

• Programmable: Yes

• Safety Timer: Yes

• Normal/Standard Charge Current: 0.1 - 15.0A, adjustable in 0.1A increments

• Voltage Meter: Yes

• Battery Balance Connector: JST-XH

• Battery Temperature Monitoring: Yes

• Charge Protection Circuitry: Yes

• Number of Cells: 1 - 6S Li-Ion/LiPo/LiFe, 1 - 16S NiCd/NiMH, 1 - 12S Pb

• Number of Output Ports: 1

• Power Source: AC

• Selectable Charge Rate: Yes

• Over Current Protection: Yes

• USB Power out: Yes

Includes

• 1pcs S1200 Smart G2 AC Charger
• 1pcs Power Cord
• 1pcs Product Manual
